SMA Error Codes

EVENT NUMBER MESSAGE, CAUSE & CORRECTIVE MEASURES
101
102
103
Grid fault

The grid voltage or grid impedance at the connection point of the inverter is too high. The inverter has disconnected from the utility grid.

Corrective measures:
1. Check whether the grid voltage at the connection point of the inverter is permanently in the permissible range.
2. If the grid voltage is outside the permissible range due to local grid conditions, contact the grid operator. The grid operator must agree with an adjustment of the voltage at the feed-in point or with a change of the monitored operating limits.
3. If the grid voltage is permanently within the permissible range and this message is still displayed, contact Service.

202
203
205
Grid fault

The utility grid has been disconnected, the AC cable is damaged or the grid voltage at the connection point of the inverter is too low. The inverter has disconnected from the utility grid.

Corrective measures:
1. Ensure that the circuit breaker is switched on.
2. Ensure that the AC cable is not damaged and that it is connected correctly.
3. Ensure that the country data set has been configured correctly.
4. Check whether the grid voltage at the connection point of the inverter is permanently in the permissible range.
5. If the grid voltage is outside the permissible range due to local grid conditions, contact the grid operator. The grid operator must agree with an adjustment of the voltage at the feed-in point or with a change of the monitored operating limits.
6. If the grid voltage is permanently within the permissible range and this message is still displayed, contact the Service.

301 Grid fault

The ten-minute average value of the grid voltage is no longer within the permissible range. The grid voltage or grid impedance at the connection point is too high. The inverter disconnects from the utility grid to maintain power quality.

Corrective measures:
1. During the feed-in operation, check whether the grid voltage at the connection point of the inverter is permanently in the permissible range.
2. If the grid voltage is outside the permissible range due to local grid conditions, contact the grid operator. The grid operator must agree with an adjustment of the voltage at the feed-in point or with a change of the monitored operating limits.
3. If the grid voltage is permanently within the permissible range and this message is still displayed, contact Service.

302 Active power limit AC voltage

The inverter has reduced its power due to a too-high grid voltage to ensure grid stability.

Corrective measures:
1. If possible, check the grid voltage and observe how often fluctuations occur. If fluctuations occur frequently and this message is displayed often, contact the grid operator and request approval to change the operating parameters of the inverter. If the grid operator gives his approval, discuss any changes to the operating parameters with the Service.

401
404
Grid fault

The inverter has disconnected from the utility grid. A stand-alone grid or a very large change in the power frequency was detected.

Corrective measures:
1. Check the grid connection for significant short-term frequency fluctuations.

501 Grid fault

The power frequency is not within the permissible range. The inverter has disconnected from the utility grid.

Corrective measures:
1. If possible, check the power frequency and observe how often fluctuations occur.
2. If fluctuations occur frequently and this message is displayed often, contact the grid operator and request approval to change the operating parameters of the inverter.
3. If the grid operator gives his approval, discuss any changes to the operating parameters with the Service.

601 Grid fault

The inverter has detected an excessively high proportion of direct current in the grid current.

Corrective measures:
1. Check the grid connection for direct current.
2. If this message is displayed frequently, contact the grid operator and check whether the monitoring threshold on the inverter can be raised.

701 Frequency not permitted > Check parameter

The power frequency is not within the permissible range. The inverter has disconnected from the utility grid.

Corrective measures:
1. If possible, check the power frequency and observe how often fluctuations occur.
2. If fluctuations occur frequently and this message is displayed often, contact the grid operator and request approval to change the operating parameters of the inverter.
3. If the grid operator gives his approval, discuss any changes to the operating parameters with the Service.

901 PE connection missing > Check connection

The grounding conductor is not correctly connected.

Corrective measures:
1. Ensure that the grounding conductor is correctly connected.

EVENT NUMBER MESSAGE, CAUSE & CORRECTIVE MEASURE
1001 L / N swapped > Check connection

The connection of L and N is swapped.

Corrective measures:
1. Ensure that L and N are correctly connected.

1101 Installation fault > Check connection

A second line conductor is connected to N.

Corrective measures:
1. Connect the neutral conductor to N.

1302 Waiting for grid voltage > Installation failure grid connection > Check grid and fuses

L or N not connected.

Corrective measures:
1. Ensure that L and N are connected.
2. Ensure that the circuit breaker is switched on.
3. Ensure that the AC cable is not damaged and that it is connected correctly.

1501 Reconnection fault grid

The changed country data set or the value of a parameter you have set does not correspond to the local requirements. The inverter cannot connect to the utility grid.

Corrective measures:
1. Ensure that the country data set has been configured correctly. To do this, select the parameter Set country standard and check the value.

EVENT NUMBER MESSAGE, CAUSE & CORRECTIVE MEASURE
3301
3302
3303
Unstable operation

There is not enough power at the DC input of the inverter for stable operation. The inverter cannot connect to the utility grid.

Corrective measures:
1. Ensure that the PV array is designed correctly.
2. Ensure that the PV array is not covered by snow or otherwise shaded.
3. Ensure that the PV array is free of errors.

3401
3402
3407
DC overvoltage > Disconnect generator

Overvoltage at the DC input. This can destroy the inverter.

This message is signalized additionally by rapid flashing of the LEDs.

Corrective measures:
1. Immediately disconnect the inverter from all voltage sources.
2. Check whether the DC voltage is below the maximum input voltage of the inverter. If the DC voltage is below the maximum input voltage of the inverter, reconnect the DC connectors to the inverter.
3. If the DC voltage exceeds the maximum input voltage of the inverter, ensure that the PV array has been correctly rated or contact the installer of the PV array.
4. If this message is repeated frequently, contact the Service.

3501 Insulation failure > Check generator

The inverter has detected a ground fault in the PV array.

Corrective measures:
1. Check the PV system for ground faults.

3701 Residual current too high > Check generator

The inverter has detected a residual current due to temporary grounding of the PV array.

Corrective measures:
1. Check the PV system for ground faults.

3801
3802
3805
DC overcurrent > Check generator

Overcurrent at the DC input. The inverter briefly interrupts feed-in operation.

Corrective measures:
1. If this message is displayed frequently, ensure that the PV array has been correctly rated and wired.

3901
3902
Waiting for DC start conditions > Start conditions not met

The feed-in conditions for the utility grid are not yet fulfilled.

Corrective measures:
1. Ensure that the PV array is not covered by snow or otherwise shaded.
2. Wait for higher irradiation.
3. If this message is displayed frequently in the morning, increase the voltage limit for starting grid feed-in. Change the parameter Critical voltage to start feed-in.
4. If this message is displayed frequently with medium irradiation, ensure that the PV array is correctly rated.

EVENT NUMBER MESSAGE, CAUSE & CORRECTIVE MEASURE
4011 Bridged strings determined

The DC inputs A and B are connected in parallel.

4012 No bridged strings determined

The DC inputs A and B are not connected in parallel.

EVENT NUMBER MESSAGE, CAUSE & CORRECTIVE MEASURE
6002-6412 Self-diagnosis > Interference device

The cause must be determined by the Service.

Corrective measures:
Contact the Service.

6501
6502
6509
Self-diagnosis > Overtemperature

The inverter has switched off due to excessive temperature.

Corrective measures:
Clean the cooling fins on the rear of the enclosure and the air ducts on the top using a soft brush.
Ensure that the inverter has sufficient ventilation.
Ensure that the ambient temperature does not exceed +40 °.
Ensure that the inverter is not exposed to direct solar irradiation.

6512 Minimum operating temperature not reached

The inverter will only recommence grid feed-in once the temperature has reached at least −25°C.

6602
6603
6604
Self-diagnosis > Overload

The cause must be determined by the Service.

Corrective measures:
Contact the Service.

6801
6802
Self-diagnosis > Input A defective

Corrective measures:
Check whether a string is connected to input A.
Contact the service.

6901
6902
Self-diagnosis > Input B defective

Corrective measures:
Check whether a string is connected to input B.
Contact the service.

6701
6702
Communication disturbed

Error in the communication processor, the inverter continues feeding in, however. The cause must be determined by the Service.

Corrective measures:
If this message is displayed frequently, contact the Service.

EVENT NUMBER MESSAGE, CAUSE & CORRECTIVE MEASURE
7102 Parameter file not found or defective

The parameter file was not found or is defective. The update failed. The inverter continues to feed in.

Corrective measures:
Copy the parameter file to the correct folder again.

7105 Parameter setting failed

Parameters could not be set using the memory card. The inverter continues to feed in.

Corrective measures:
Ensure that the parameters are set correctly.
Ensure that the SMA Grid Guard code is available.

7106 Update file defective

The update file is defective. The update failed. The inverter continues to feed in.

7110 No update file found

No new update file was found on the SD memory card. The update failed. The inverter continues to feed in.

7112 Update file successfully copied
7113 The memory card is full or write-protected
7201 – 7202 Data storage not possible
7303 Update main CPU failed

The cause must be determined by the Service.

Corrective measures:
Contact the Service.

7320 The device was successfully updated

The firmware update was completed successfully.

7330 Condition test failed

The testing of the update conditions was successful. The firmware update package is suitable for this inverter.

7331 Update transport started

Update file is being copied.

7332 Update transport successful

Update file was copied successfully to the inverter’s internal memory.

7333 Update transport failed

Update file could not be copied to the inverter’s internal memory. In the event of connection with the inverter via WLAN, a poor connection quality can be the cause.

Corrective measures:
Retry update.
For WLAN connection: Improve the WLAN connection quality (e.g., via WLAN repeater) or establish a connection with the inverter via Ethernet.
If this message is displayed again, contact the Service.

7341 Update Bootloader

The inverter is performing a bootloader update.

7342 Update Bootloader failed

The bootloader update failed.

Corrective measures:
Retry update.
If this message is displayed again, contact the Service.

7347 Incompatible file

The configuration file is not suitable for this inverter.

Corrective measures:
Ensure that the selected configuration file is suitable for this inverter.
Retry import.

7348 Incorrect file format

The configuration file is not of the required format or is damaged.

Corrective measures:
Ensure that the selected configuration file is of the required format and is not damaged.
Retry import.

7349 Incorrect login rights for configuration file

The user group logged in does not have the user rights necessary to be able to import a configuration.

Corrective measures:
Log in as Installer.
Import configuration file again.

7350 Transfer of a configuration file has started

The configuration file is being transferred.

7351 Update WLAN

The inverter is updating the WLAN module.

7352 Update of WLAN not successful

The update of the WLAN module failed.

Corrective measures:
Retry update.
If this message is displayed again, contact the Service.

7353 Update time zone database

The inverter is updating the time zone database.

7354 Update of time zone database not successful

The update of the time zone database failed.

Corrective measures:
Retry update.
If this message is displayed again, contact the Service.

7355 Update WebUI

The inverter is updating the inverter user interface.

7356 Update of the WebUI not successful

The update of the inverter user interface failed.

Corrective measures:
Retry update.
If this message is displayed again, contact the Service.

7500 – 7501 Fan fault > Check inverter electr. and fan

Corrective measures:
Contact the Service.

7619 Communication fault with meter unit > Check communication to meter

The inverter is not receiving any data from the energy meter.

Corrective measures:
Ensure that the energy meter is correctly integrated into the same network as the inverter (see energy meter manual).
For WLAN connection: Improve the WLAN connection quality (e.g., via WLAN repeater) or connect the inverter with the DHCP server (router) via Ethernet.

7702 Interference device

The cause must be determined by the Service.

Corrective measures:
Contact the Service.

EVENT NUMBER MESSAGE, CAUSE & CORRECTIVE MEASURE
8003 Active power limit Temperature

The inverter has reduced its power output for more than ten minutes due to excessive temperature.

Corrective measures:
Clean the cooling fins on the rear of the enclosure and the air ducts on the top using a soft brush.
Ensure that the inverter has sufficient ventilation.
Ensure that the ambient temperature does not exceed +40 °.
Ensure that the inverter is not exposed to direct solar irradiation.

8101 – 8104 Communication disturbed

The cause must be determined by the Service.

Corrective measures:
Contact the Service.

9002 SMA Grid Guard code invalid

The SMA Grid Guard code entered is incorrect. The operating parameters are still protected and cannot be changed.

Corrective measures:
Enter the correct SMA Grid Guard code.

9003 Grid parameter locked

Changes to the grid parameters are now blocked. In order to be able to make changes to the grid parameters, from now on you must log in using the SMA Grid Guard code.

9005 Changing of grid parameters not possible > Ensure DC supply

This error can have the following causes:
The parameters to be changed are protected.
The DC voltage at the DC input is not sufficient to run the main CPU.

Corrective measures:
Enter the SMA Grid Guard code.
Ensure that at least the DC start voltage is available (green LED is flashing, pulsing or glowing).

9007 Abort self-test

The self-test (Italy only) was terminated.

Corrective measures:
Ensure that the AC connection is correct.
Restart the self-test.

EVENT NUMBER MESSAGE, CAUSE & CORRECTIVE MEASURE
10108 Time adjusted / old time
10109 Time adjusted / new time
10110 Time synchronization failed: |tn0|

No time information could be called up from the set NTP server.

Corrective measures:
Ensure that the NTP server was configured correctly.
Ensure that the inverter is integrated into a local network with an Internet connection.

10118 Parameter upload complete
The configuration file was loaded successfully.
10248 [Interface]: network busy

The network is busy. Data exchange between the devices is not at an optimum and is greatly delayed.

Corrective measures:
Increase the query intervals.
If necessary, reduce the number of devices in the network.

10249 [Interface]: network overloaded

The network is overloaded. There is no data exchange between the devices.

Corrective measures:
Reduce the number of devices in the network.
If necessary, increase the data query intervals.

10250 [Interface]: package error rate [ok / high]

The package error rate has changed. If the package error rate is high, the network is overloaded or the connection to the network switch or DHCP server (router) is disturbed.

Corrective measures if the package error rate is high:
Ensure that with an Ethernet connection, the network cable and the network connector are not damaged and that the network connectors are correctly plugged.
If necessary, increase the data query intervals.
If necessary, reduce the number of devices in the network.

10251 [Interface]: communication status goes to [OK / Warning / Error / Not connected]

The communication status to the network switch or DHCP server (router) has changed. An additional error message may be displayed.

10252 [Interface]: communication disrupted

There is no valid signal on the network line.

Corrective measures:
Ensure that with an Ethernet connection, the network cable and the network connector are not damaged and that the network connectors are correctly plugged.
Ensure that the DHCP server (router) and any network switches are signalizing correct operation.

10253 [Interface]: connection speed goes to [100 Mbit / 10 Mbit]

The data transfer rate has changed. The cause for the status [10 Mbit] can be a defective plug, a defective cable, or the pulling or plugging of the network connector.

Corrective measures if the status is [10 Mbit]:
Ensure that with an Ethernet connection, the network cable and the network connector are not damaged and that the network connectors are correctly plugged.
Ensure that the DHCP server (router) and any network switches are signalizing correct operation.

10254 [Interface]: duplex mode goes to [Full / Half]

The duplex mode (data transfer mode) has changed. The cause for the status [Half] can be a defective plug, a defective cable, or the pulling or plugging of the network connector.

Corrective measures if the status is [Half]:
Ensure that with an Ethernet connection, the network cable and the network connector are not damaged and that the network connectors are correctly plugged.
Ensure that the DHCP server (router) and any network switches are signalizing correct operation.

10255 [Interface]: Network load OK
The network load has returned to a normal range after being busy.
10282 [User group]-Login via [protocol] locked

After several incorrect login attempts, login has been blocked for a limited time. In this case, the User login will be blocked for 15 minutes, the Grid Guard login for 12 hours.

Corrective measures:
Wait until the given time has expired and then retry login.

10283 WLAN module faulty

The WLAN module integrated in the inverter is defective.

Corrective measures:
Contact the Service.

10284 No WLAN connection possible

The inverter does not currently have a WLAN connection to the selected network.

Corrective measures:
Ensure that the SSID, the WLAN password, and the encryption method have been entered correctly. The encryption method is specified by your WLAN router or WLAN Access Point and can be changed there.
Ensure that the WLAN router or WLAN Access Point is in range and is signalizing correct operation.
If this message is displayed often, improve the WLAN connection by using a WLAN repeater.

10285 WLAN connection established
Connection to the selected WLAN network has been established.
10286 WLAN connection lost

The inverter has lost WLAN connection to the selected network.

Corrective measures:
Ensure that the WLAN router or WLAN Access Point is still active.
Ensure that the WLAN router or WLAN Access Point is in range and is signalizing correct operation.
If this message is displayed often, improve the WLAN connection by using a WLAN repeater.

10339 Webconnect enabled
The Webconnect function has been enabled.
10340 Webconnect disabled
The Webconnect function has been disabled.
10502 Active power limit AC frequency

The inverter has reduced its power due to a too-high power frequency to ensure grid stability.

Corrective measures:
If possible, check the power frequency and observe how often fluctuations occur. If fluctuations occur frequently and this message is displayed often, contact the grid operator and request approval to change the operating parameters of the inverter. If the grid operator gives his approval, discuss any changes to the operating parameters with the Service.

10901 Self-test start [xx]
The self-test is running.
10902 Current disconnection limit for voltage increase protection [xxx] V
Preliminary result of the self-test
10903 Current disconnection limit for voltage monitoring lower maximum threshold [xxx] V
Preliminary result of the self-test
10904 Current disconnection limit for voltage monitoring upper minimum threshold [xxx] V
Preliminary result of the self-test
10905 Current disconnection limit for voltage monitoring middle minimum threshold [xxx] V
Preliminary result of the self-test
10906 Current disconnection limit for frequency monitoring switchable maximum threshold |xxx| Hz
Preliminary result of the self-test
10907 Current disconnection limit for frequency monitoring switchable minimum threshold [xxx] Hz
Preliminary result of the self-test
10908 Current disconnection limit for frequency monitoring switchable minimum threshold [xxx] Hz
Preliminary result of the self-test
10909 Current disconnection limit for frequency monitoring upper minimum threshold [xxx] Hz
Preliminary result of the self-test
10910 Measured disconnection threshold for the running test point [xxx] [xx]
Preliminary result of the self-test
10911 Measured disconnection threshold for the running test point [xxx] [xx]
Preliminary result of the self-test
10912 Measured disconnection time for the running test point [xx] s
Preliminary result of the self-test
EVENT NUMBER MESSAGE, CAUSE & CORRECTIVE MEASURE
27103 Set parameter

The parameter changes are being adopted.

27104 Parameters set successfully
The parameter changes were successfully adopted.
27107 Update file OK
The update file found is valid.
27301 Update communication
The inverter is updating the communication component.
27302 Update main CPU
The inverter is updating the inverter component.
27312 Update completed
The inverter has successfully completed the update.
29001 Installer code valid
The entered Grid Guard code is valid. Protected parameters have now been unlocked and you can adjust the parameters. The parameters will be automatically locked again after ten feed-in hours.
29004 Grid parameters unchanged
Changing the grid parameters is not possible.

South East Queensland SMA Inverter Technicians

Fallon Solutions can take care of all your SMA Solar Inverter issues and offer upgrades to your solar installation or we can offer a 26 point safety check of your existing system. Simply call us on 1300 054 488 or fill in an online solar inverter enquiry form and one of our friendly team will contact you.

Keep your SMA inverter running at optimal performance with regular maintenance, preventing unexpected breakdowns and costly repairs. Maximise your return on investment by guaranteeing excellent energy production from your solar panels. Properly functioning and serviced inverters will enable the safe and efficient conversion of DC power to AC power.

csm_Sunny_Boy_1.5-2.5_52f685105f

24/7 Emergency Electricians

Our master electricians are available 24/7 for emergency services in Greater Brisbane & Gold Coast. Offering you peace of mind in stressful circumstances, you can trust that a Fallon Solutions electrician will be there promptly when you need them.

Electrical emergency services are available to residents of:

  • Brisbane
  • Ipswich
  • Logan
  • Moreton Bay
  • Redlands
  • Gold Coast

For residential or commercial electrical emergencies, call us on 1300 054 488.

Fallon Solutions Solar Electricians

Same-Day Service: Our electricians are available across Greater Brisbane, the Gold Coast and the Sunshine Coast so you never have to look far for our trusted technicians.

24/7 Emergency Electrician Service: We are proud to offer emergency electricians to residents of Greater Brisbane & the Gold Coast.

Excellent Customer Service: With thousands of 5-star reviews, we know the importance of quality customer service. Let us guide you through solar installation, repairs and services.

Highly Qualified & Knowledgeable: Our team of solar specialists are experts in their field. With up-to-date qualifications, insurance and extensive knowledge.

Trusted by over 5,700 reviewers on Google.

Rated 4.5 stars from more than 5,700 reviews

All reviews    Leave a review
